AVRON CABLE

H03VVH2-F CABLE
TECHNICAL INFORMATION

Name: H03VVH2-F Cable
Brand: Avron Cable

Type

H03VVH2-F

Standards

TS 9760 IEC 227, VDE 0281, BS 6500

Construction

1- Fine stranded copper conductor
2- PVC insulation
3- PVC outer sheath

Applications

Flat flexible cable designed for use in household appliances operating under light mechanical stress and in damp environments.

Technical Data

Max. operating temperature: 70°C
Max. short-circuit temperature: 160°C

What Is H03VVH2-F Cable?

H03VVH2-F cable is a flat flexible electrical cable with thin insulation, designed for low-voltage applications. Its fine stranded copper conductor provides excellent flexibility, while its PVC insulation and PVC outer sheath make it ideal for household use, office installations, light-duty electrical systems, and small electrical appliance connections.

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Dış Çap min - max mm	Yaklaşık Dış Çap max. mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Pipe A - Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Overall Diameters in Standards min - max mm	Approx. Overall Diameter max. mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Pipe A - Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Наружный диаметр по стандарту мин - макс мм	Приблизительный наружный диаметр макс. мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Pipe A - Air A
2 x 0,50	15 x 0,20	0,5 - 0,6	3,0 x 4,9	39,00	30	- - 3
2 x 0,75	22 x 0,20	0,5 - 0,6	3,2 x 5,20	26,00	39	- - 6

H03VVH2-F Cable Technical Specifications

Type: H03VVH2-F
Standard: TS 9760 IEC 227, VDE 0281, BS 6500
Conductor: Fine stranded copper conductor
Insulation: PVC insulation
Outer Sheath: PVC outer sheath
Construction: Flat and flexible cable design
Operating Temperature: Maximum 70°C
Short-Circuit Temperature: Maximum 160°C
Rated Voltage: 300/300 V

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Dış Çap min - max mm	Yaklaşık Dış Çap max. mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Pipe A - Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Overall Diameters in Standards min - max mm	Approx. Overall Diameter max. mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Pipe A - Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Наружный диаметр по стандарту мин - макс мм	Приблизительный наружный диаметр макс. мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Pipe A - Air A
2 x 0,50	15 x 0,20	0,5 - 0,6	3,0 x 4,9	39,00	30	- - 3
2 x 0,75	22 x 0,20	0,5 - 0,6	3,2 x 5,20	26,00	39	- - 6

H03VVH2-F Cable Applications

H03VVH2-F cable is used for low-power electrical connections, household appliances, office equipment, lighting fixtures, light-duty electrical installations, and indoor applications exposed to minimal mechanical stress. Its flat and flexible design provides easy installation in confined spaces and at movable connection points.

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Dış Çap min - max mm	Yaklaşık Dış Çap max. mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Pipe A - Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Overall Diameters in Standards min - max mm	Approx. Overall Diameter max. mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Pipe A - Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Наружный диаметр по стандарту мин - макс мм	Приблизительный наружный диаметр макс. мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Pipe A - Air A
2 x 0,50	15 x 0,20	0,5 - 0,6	3,0 x 4,9	39,00	30	- - 3
2 x 0,75	22 x 0,20	0,5 - 0,6	3,2 x 5,20	26,00	39	- - 6

Advantages of H03VVH2-F Cable

Provides excellent flexibility thanks to its fine stranded copper conductor
Its flat cable design allows for easy installation in confined spaces
Ensures safe power transmission with PVC insulation and a PVC outer sheath
Ideal for household appliances and light-duty electrical applications
Offers an economical and reliable solution for low-power indoor electrical connections

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Dış Çap min - max mm	Yaklaşık Dış Çap max. mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Pipe A - Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Overall Diameters in Standards min - max mm	Approx. Overall Diameter max. mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Pipe A - Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Наружный диаметр по стандарту мин - макс мм	Приблизительный наружный диаметр макс. мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Pipe A - Air A
2 x 0,50	15 x 0,20	0,5 - 0,6	3,0 x 4,9	39,00	30	- - 3
2 x 0,75	22 x 0,20	0,5 - 0,6	3,2 x 5,20	26,00	39	- - 6

Frequently Asked Questions

About H03VVH2-F Cable

Below you can find answers to the most frequently asked questions about the applications, technical specifications, standards, flat flexible construction, and supply process of H03VVH2-F Cable manufactured by Avron Cable.

H03VVH2-F cable is a flat flexible cable with a fine stranded copper conductor, PVC insulation, and a PVC outer sheath. It is manufactured in accordance with TS 9760 IEC 227, VDE 0281, and BS 6500 standards.

H03VVH2-F cable is used in household appliances, office equipment, lighting connections, low-power electrical devices, and light-duty electrical installations.

H03VVH2-F cable consists of a fine stranded copper conductor, PVC insulation, and a PVC outer sheath. It has a rated voltage of 300/300 V, a maximum operating temperature of 70°C, and a maximum short-circuit temperature of 160°C.

Yes. H03VVH2-F cable offers excellent flexibility thanks to its fine stranded copper conductor. This feature makes it ideal for installations in confined spaces and light-duty movable connections.

H03VVH2-F cable is manufactured in compliance with TS 9760 IEC 227, VDE 0281, and BS 6500 standards. These standards define the cable's safety, performance, and application requirements.

H03VVH2-F cable is generally intended for indoor and light-duty applications. It is not suitable for heavy mechanical stress, continuous outdoor exposure, or heavy industrial environments.

The appropriate H03VVH2-F cable size should be selected based on the equipment power, required current, cable length, and application. Choosing the correct size is essential for safe power transmission in light-duty installations.

You can request a fast quotation by providing the required H03VVH2-F cable size, number of cores, and quantity. Our technical team can also assist you in selecting the most suitable cable solution for your project.
