Where is NYIFY-F cable used?

NYIFY-F cables are used in lighting systems, socket circuits, fixed indoor installations and in areas with low mechanical stress.

AVRON CABLE

NYIFY-F CABLE
TECHNICAL INFORMATION

Type

NYIFY-F

Standards

TS IEC 332-1, VDE 0250

Structure

1- Fine stranded copper conductor
2- PVC insulation
3- PVC outer sheath

Applications

The cable is flexible and suitable for installation in cable ducts. It is used as a power, lighting, and distribution cable. It can be used in indoor and outdoor areas where there is no excessive mechanical stress.

Technical Data

Max. operating temperature 70°C
Max. short-circuit temperature 160°C

What is NYIFY-F Cable?

NYIFY-F cable is a flat-type low-voltage power cable used in electrical installations. Thanks to its fine stranded copper conductor, it offers flexible installation. It is commonly used in residential, commercial, and industrial buildings for lighting, socket circuits, and fixed wiring applications to ensure safe power transmission.

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Et Kalınlığı (İzole) mm	Standart Et Kalınlığı (Kılıf) mm	Maks. Dış Çap mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Thickness of Insulation mm	Thickness of Sheath mm	Overall Diameter Max mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Толщина изоляции мм	Толщина оболочки мм	Макс. наружный диаметр мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Air A
2 x 1	30 x 0,20	0,4	0,8	3,3 x 9,6	18,1	44	12
2 x 1,5	27 x 0,25	0,4	0,8	4,4 x 12	12,1	59	19
2 x 2,5	45 x 0,25	0,5	0,8	5,2 x 13,5	7,41	90	25
2 x 4	50 x 0,30	0,6	0,9	6,2 x 15,5	4,61	127	34
3 x 1	30 x 0,20	0,4	0,8	3,3 x 10,1	18,1	65	12
3 x 1,5	27 x 0,25	0,4	0,8	4,4 x 19	12,1	89	19
3 x 2,5	45 x 0,25	0,5	0,9	5,2 x 21,5	7,41	135	25
3 x 4	50 x 0,30	0,6	0,9	6,2 x 25	4,61	191	34

NYIFY-F Kablo Teknik Özellikleri

Tip: NYIFY-F
Standart: TS IEC 332-1, VDE 0250
İletken: İnce çok telli bakır iletken
İzolasyon: PVC izole
Dış Kılıf: PVC dış kılıf
Çalışma Sıcaklığı: Maksimum 70°C
Kısa Devre Sıcaklığı: Maksimum 160°C

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Et Kalınlığı (İzole) mm	Standart Et Kalınlığı (Kılıf) mm	Maks. Dış Çap mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Thickness of Insulation mm	Thickness of Sheath mm	Overall Diameter Max mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Толщина изоляции мм	Толщина оболочки мм	Макс. наружный диаметр мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Air A
2 x 1	30 x 0,20	0,4	0,8	3,3 x 9,6	18,1	44	12
2 x 1,5	27 x 0,25	0,4	0,8	4,4 x 12	12,1	59	19
2 x 2,5	45 x 0,25	0,5	0,8	5,2 x 13,5	7,41	90	25
2 x 4	50 x 0,30	0,6	0,9	6,2 x 15,5	4,61	127	34
3 x 1	30 x 0,20	0,4	0,8	3,3 x 10,1	18,1	65	12
3 x 1,5	27 x 0,25	0,4	0,8	4,4 x 19	12,1	89	19
3 x 2,5	45 x 0,25	0,5	0,9	5,2 x 21,5	7,41	135	25
3 x 4	50 x 0,30	0,6	0,9	6,2 x 25	4,61	191	34

NYIFY-F Cable Applications

NYIFY-F cables are used for lighting systems, socket installations, fixed indoor wiring, and in enclosed areas where mechanical stress is low, ensuring safe power transmission. Thanks to its flat structure, it can also be preferred in applications suitable for nail fixing between partitions.

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Et Kalınlığı (İzole) mm	Standart Et Kalınlığı (Kılıf) mm	Maks. Dış Çap mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Thickness of Insulation mm	Thickness of Sheath mm	Overall Diameter Max mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Толщина изоляции мм	Толщина оболочки мм	Макс. наружный диаметр мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Air A
2 x 1	30 x 0,20	0,4	0,8	3,3 x 9,6	18,1	44	12
2 x 1,5	27 x 0,25	0,4	0,8	4,4 x 12	12,1	59	19
2 x 2,5	45 x 0,25	0,5	0,8	5,2 x 13,5	7,41	90	25
2 x 4	50 x 0,30	0,6	0,9	6,2 x 15,5	4,61	127	34
3 x 1	30 x 0,20	0,4	0,8	3,3 x 10,1	18,1	65	12
3 x 1,5	27 x 0,25	0,4	0,8	4,4 x 19	12,1	89	19
3 x 2,5	45 x 0,25	0,5	0,9	5,2 x 21,5	7,41	135	25
3 x 4	50 x 0,30	0,6	0,9	6,2 x 25	4,61	191	34

NYIFY-F Cable Advantages

Flexible and easy-to-install flat cable structure
Safe energy transmission thanks to fine stranded copper conductor
Durable usage with PVC insulation and PVC outer sheath
Suitable for lighting, socket, and fixed installation applications
Practical and long-lasting solution for low-voltage applications

Nominal Kesit No x mm²	İletken Tel Sayısı ve Çapı No x mm	Standart Et Kalınlığı (İzole) mm	Standart Et Kalınlığı (Kılıf) mm	Maks. Dış Çap mm	20°C'de Maks. İletken DC Direnci Ω/km	Yaklaşık Toplam Ağırlık kg/km	30°C'de Maks. Akım Taşıma Kapasitesi Air A
Num. of Cores and Nominal Cross Section No x mm²	Number of Wires and Diameter No x mm	Thickness of Insulation mm	Thickness of Sheath mm	Overall Diameter Max mm	Conductor DC Resistance at 20°C Ω/km	Approx. Total Weight kg/km	Max. Current Carrying Capacity at 30°C Air A
Номинальное сечение No x мм²	Количество проволок и диаметр No x мм	Толщина изоляции мм	Толщина оболочки мм	Макс. наружный диаметр мм	Сопротивление проводника при 20°C Ом/км	Приблизительный общий вес кг/км	Макс. токовая нагрузка при 30°C Air A
2 x 1	30 x 0,20	0,4	0,8	3,3 x 9,6	18,1	44	12
2 x 1,5	27 x 0,25	0,4	0,8	4,4 x 12	12,1	59	19
2 x 2,5	45 x 0,25	0,5	0,8	5,2 x 13,5	7,41	90	25
2 x 4	50 x 0,30	0,6	0,9	6,2 x 15,5	4,61	127	34
3 x 1	30 x 0,20	0,4	0,8	3,3 x 10,1	18,1	65	12
3 x 1,5	27 x 0,25	0,4	0,8	4,4 x 19	12,1	89	19
3 x 2,5	45 x 0,25	0,5	0,9	5,2 x 21,5	7,41	135	25
3 x 4	50 x 0,30	0,6	0,9	6,2 x 25	4,61	191	34

Frequently Asked Questions

NYIFY-F Cable Information

Below you can find answers to the most frequently asked questions about NYIFY-F cable produced by Avron Cable, including its applications, technical specifications, standards, manufacturing quality, and supply process.

NYIFY-F cable is a flexible and durable low-voltage power cable with fine stranded copper conductor, PVC insulation, and PVC outer sheath. It is manufactured in compliance with TS IEC 332-1 and VDE 0250 standards.

NYIFY-F cable is used in residential buildings, commercial structures, lighting installations, socket circuits, concealed wiring systems, and fixed electrical installations for safe power transmission.

NYIFY-F cable features fine stranded copper conductor with PVC insulation and PVC outer sheath. It operates at 300/500 V rated voltage and complies with TS IEC 332-1 and VDE 0250 standards.

Yes. NYIFY-F cable offers high flexibility thanks to its fine stranded copper conductor, making installation easier, especially in narrow or difficult spaces.

NYIFY-F cable is manufactured in compliance with TS IEC 332-1 and VDE 0250 standards, which define safety, durability, and performance requirements.

Yes. NYIFY-F cable is widely used in indoor building installations, lighting systems, and fixed power distribution lines.

Cable size should be selected based on current load, cable length, voltage drop, and application requirements. Proper sizing ensures safe and efficient energy transmission.

You can request a quick quotation by providing cable size, number of cores, and quantity. Technical support is also available for selecting the most suitable cable solution for your project.
